Three-position Full Function
Explore detailed specifications, features and application information for this product.
Three-position Full Function
Gauge: 12G 14G 16G 18G
Breadth： 40" 52" 72" 80"
| Gauge | 12G 14G 16G 18G | |
| Knitting Width | 40" 52" 72" | 72" 80" |
| Knitting System | Single carriage three system | |
| Power | 0.75kw | 0.85kw |
| Knitting Function | Transfer、Knitting、Tuck、Intarsia、Jacquard、Narrowing | |
| Knitting Speed | Controlled by servo motor, Max 1.2m/s, Carriage rapid return | |
| Racking | Controlled by servo motor racing within 1 inch and with fine micro-adjustment function | |
| Stitch Density | Controlled by stepping motor, selectable adjustable scope supported by subdivision technology: 0–650, the stitch of the collar can be accurately controlled | |
| Take Down Roller | Programmed instruction controlled Up and down take down system, It can work separately or together. Adjustable range is: 0–99 | |
| Yarn Carrier | 8 colors, two side interchangeable feeders | |
| Protecting | The machine will automatic alarm if yarn-breaking knots floating yarn rewind end of knitting, fail of racking needle breakage error programming occur also set up the safety auto-lock protect device | |
| Operation Display | Chinese、English、Korean、Spanish、Portuguese、Turkish、French、Arabic | |
| Power Supply | AC Single Phase 220V 50HZ, adopt advanced CMOS technology, Instantaneous memory of power outage (continues knitting when power on) | |
| N.W. | 950kg | |
| Length | 2600 × 900 × 1800mm | |
Three-position Full Function is listed among collar machines and the Sinker + Full-function SJ Series. Its published gauge options are 12G, 14G, 16G and 18G, with 40-, 52-, 72- and 80-inch breadths across the summary and specification columns. The table calls the knitting arrangement a single-carriage three-system configuration. Buyers should confirm the precise width and configuration proposed for their application because the separate table columns do not imply that all listed figures belong to a single machine.
Use a real collar sample, technical drawing or other intended article as the selection brief. Identify the yarn, stitch structure, design file and final dimensions, then mark where transfer, narrowing, tuck, intarsia or jacquard is required. The function list provides a basis for discussing these details, but an application-specific knit trial remains the appropriate way to review the result. Agree with the supplier on what the sample should demonstrate and how dimensions and appearance will be checked.
The stated racking, take-down and stitch-density settings are useful when discussing pattern preparation and operator adjustments. They should not be converted into claims about a production run or product quality without material-specific testing. Match the working width to the planned article and verify the actual physical dimensions and site power of the quoted machine. Discuss operator access, installation space and any language requirement before specifying the final control configuration.
For an inquiry, send the sample, gauge and width preference, yarn composition and count, pattern requirements, installation location and local voltage. Ask for a machine-specific specification, a sampling process and the scope of operator training. Maintenance planning should include the manufacturer’s instructions for cleaning, checking needles and yarn carriers, and responding to the listed alarm conditions. Confirm documentation, spare-part identification and support arrangements with the supplier. The page does not establish a price, delivery schedule or guaranteed output for a particular design.
