Mini Jacquard
Explore detailed specifications, features and application information for this product.
Mini Jacquard
Gauge : 12G 14G 16G 18G 20G 22G
Breadth : 42" 52" 68" 72" 80" 100"
| Gauge | 12G 14G 16G 18G 20G 22G | |
| Knitting Width | 42" 52" 68" 72" 80" 100" | 72" 80" |
| Knitting System | Single carriage | Double carriage |
| Power | 0.35kw | 0.55kw |
| Knitting Function | Knitting、Mini Jacquard、High-pin、Low-pin needles | |
| Knitting Speed | Controlled by servo motor, Max 1.2m/s, Carriage rapid return | |
| Racking | Controlled by servo motor racing within 1 inch and with fine micro-adjustment function | |
| Stitch Density | Controlled by stepping motor, selectable adjustable scope supported by subdivision technology: 0–650, the stitch of the collar can be accurately controlled | |
| Take Down Roller | Programmed instruction controlled Up and down take down system, It can work separately or together. Adjustable range is: 0–99 | |
| Yarn Carrier | 8 colors, two side interchangeable feeders | |
| Protecting | The machine will automatic alarm if yarn-breaking knots floating yarn rewind end of knitting, fail of racking needle breakage error programming occur also set up the safety auto-lock protect device | |
| Operation Display | Chinese、English、Korean、Spanish、Portuguese、Turkish、French、Arabic | |
| Power Supply | AC Single Phase 220V 50HZ, adopt advanced CMOS technology, Instantaneous memory of power outage (continues knitting when power on) | |
| N.W. | 550kg | |
| Length | 2500 × 900 × 1800mm | |
Mini Jacquard is listed for collar and shoe-upper applications as well as the Mini Jacquard M Series. Its stated gauge choices are 12G, 14G, 16G, 18G, 20G and 22G; the listed knitting widths are 42, 52, 68, 72, 80 and 100 inches. The specification table distinguishes single-carriage and double-carriage configurations, so a buyer should identify the carriage arrangement rather than assuming every width has the same setup.
Start selection with an actual collar or shoe-upper sample and its intended yarn. Specify the target gauge, finished dimensions and pattern details, particularly where mini jacquard or high-pin and low-pin needle effects matter. Compare the available knitting width with the planned panel layout and ask the supplier to confirm which carriage configuration is offered at that width. A width listed for the series should not be treated as proof that every gauge and carriage combination is available together.
When discussing pattern preparation, include the number of colors, any changes in stitch density and the steps required to review a trial piece. The published parameters mention eight-color yarn carriers, programmable take-down, servo-controlled racking and a 0–650 stitch-density adjustment scope. These are configuration references, not guarantees that a particular yarn or design will run without sampling. Request a demonstration or test based on the proposed material and actual design before specifying the final machine.
For a useful quotation, send the intended product, sample photos or technical drawing, yarn composition and count, desired gauge, required working width, carriage preference, voltage at the installation site and expected operator language. Ask which accessories, documentation and training are included in the proposed configuration. Keep maintenance discussion specific: confirm cleaning points, lubrication instructions, needle and carrier inspection, and the procedure for responding to the listed alarms. Agree on the recommended service routine and available support with the supplier for the actual machine supplied.
