Computer Jacquard Single System
Explore detailed specifications, features and application information for this product.
Computer Jacquard Single System
Gauge : 12G 14G 16G 18G 20G
Breadth : 40" 52" 72" 80" 100"
| Gauge | 12G 14G 16G 18G 20G | |
| Knitting Width | 40" 52" 72" 80" 100" | 72" 80" |
| Knitting System | Single carriage | Double carriage |
| Power | 0.35kw | 0.55kw |
| Knitting Function | Knitting、Tuck、Intarsia、Jacquard | |
| Knitting Speed | Controlled by servo motor, Max 1.2m/s, Carriage rapid return | |
| Racking | Controlled by servo motor racing within 1 inch and with fine micro-adjustment function | |
| Stitch Density | Controlled by stepping motor, selectable adjustable scope supported by subdivision technology: 0–650, the stitch of the collar can be accurately controlled | |
| Take Down Roller | Programmed instruction controlled Up and down take down system, It can work separately or together. Adjustable range is: 0–99. | |
| Yarn Carrier | 8 colors, two side interchangeable feeders | |
| Protecting | The machine will automatic alarm if yarn-breaking knots floating yarn rewind end of knitting, fail of racking needle breakage error programming occur also set up the safety auto-lock protect device | |
| Operation Display | Chinese、English、Korean、Spanish、Portuguese、Turkish、French、Arabic | |
| Power Supply | AC Single Phase 220V 50HZ, adopt advanced CMOS technology, Instantaneous memory of power outage (continues knitting when power on) | |
| N.W. | 600kg | |
| Length | 2500 × 900 × 1800mm | |
Computer Jacquard Single System is presented in the collar-machine, jacquard and shoe-upper categories. Its stated gauge choices are 12G, 14G, 16G, 18G and 20G, while the listed working widths include 40, 52, 72, 80 and 100 inches. The technical table separately describes single- and double-carriage columns. Buyers should verify exactly which carriage and width pairing is included in a proposal instead of assuming all combinations are interchangeable.
Selection begins with the knitted article. Send a collar or shoe-upper sample, pattern artwork, yarn details and target dimensions to the supplier. Describe whether the project needs jacquard, intarsia or tuck work and how the colors and pattern repeat should appear on the finished piece. The published eight-color yarn-carrier reference and stitch-density adjustment are useful discussion points, but the ability to reproduce a specific pattern needs a trial with the proposed material and configuration. Agree in advance how the trial will be checked for stitch appearance, dimensions and repeat accuracy.
The working width is a machine specification, not a promise about the finished dimension of a product. Ask how a sample will be laid out at the selected gauge and how the take-down settings affect that particular design. Review the published single-phase electrical reference against the installation site, and request a dimensioned layout for the quoted arrangement. A planned change from one collar to another may require a new pattern and settings; operators should have the appropriate machine-specific instructions.
For quotation, identify the intended end product, gauge, width, carriage choice, pattern file or sample, yarn composition and count, power supply and operator-language needs. Ask the supplier to state the exact scope of equipment, training and technical support. Routine care should address cleaning, needle and yarn-carrier checks and fault-alarm handling under the manufacturer’s instructions. A model-specific sample plan and written configuration are more reliable than general statements about versatility or production speed.
