Multifunctional Glove Machine
Explore detailed specifications, features and application information for this product.
Multifunctional Glove Machine
Gauge : 5/7G 7G 9G 10G 12G
Breadth ：60" 72"
| Needle Type | 5/7G 7G 9G 10G 12G |
| Weaving Amplitude | 60" 72" |
| Knitting System | Three System |
| Knitting Function | Needle, pick holes, jacquard, cable, ming narrowing, dark narrowing, variable density and other regular patterns woven |
| Control System | Screen display: LED touch screen, USB input, memory up to 8G, according to the production of call |
| Monitoring menu: displays current knitting parameters, and can be adjusted at any time when the machine is operating | |
| Plate making and control system (software): easy to upgrade, for free distribution. | |
| Multi language version: according to customer needs to increase the required language. | |
| Speed:1.5m/s | |
| Protection System | When the machine has any fault in the course of action, will automatically alarm, at the same time display alarm project |
| Power Supply | Single phase 220V, CMOS technology, has the memory function at power-off moment |
| Knitting Width | Length | Width | Height | Net Weight | Power Consumption |
|---|---|---|---|---|---|
| 60" | 2800mm | 900mm | 1800mm | 960kg | 1100W |
| 72" | 3100mm | 1000mm | 1800mm | 1100kg | 1100W |
The Multifunctional Glove Machine is listed with 5/7G, 7G, 9G, 10G and 12G gauge options, 60- and 72-inch breadths, and a three-system knitting arrangement. Its product page also includes a sample image. For a glove project, these catalog entries should be connected to the actual article: provide a reference glove or detailed drawing, the intended yarn and the size range. Ask which listed gauge and breadth apply to the proposed design rather than assuming that a single configuration covers every glove style.
The specification lists knitting, jacquard, cable, narrowing and variable-density functions among its pattern capabilities. Identify which of those functions the reference design requires and ask the supplier to explain the pattern preparation and sampling process for this machine. If the target glove has demanding shaping or visual details, assess a knitted trial piece for dimensions and appearance before committing to a production specification. The presence of a sample photograph should not be taken as evidence that a different yarn or customer design will produce an identical result.
The dimensions section gives separate physical lengths and weights for the 60- and 72-inch models. Check transport access, operator clearance and the machine’s position on the production floor against the configuration being quoted. The product’s table also identifies a power figure for the illustrated widths and the specification gives a single-phase supply reference. Confirm the actual electrical and installation requirements in the final equipment proposal, including any site-specific constraints. The catalog does not supply a project-specific output rate or pricing.
To request a meaningful quotation, send the glove application, sample image, yarn composition and count, required gauge, chosen breadth, pattern features, target size range, local voltage and desired operator language. Ask for an itemized scope of supply, model-specific instructions and a sample review process. For maintenance, discuss needle and yarn-path inspections, routine cleaning and the procedure for interpreting the displayed fault alarms. Confirm who provides operator guidance and how support is requested for the exact model ordered.
